Disconnecting Fuel Line [Need Help]

[zrace]

Here is the story, the person before me decided it would be a good idea to put the fuel line right next to the headers, and well, you can see below. I need to know how to disconnect the fuel line. I've tried several times on the way that I think it comes off. Pictures.





Zoomed out View



[Elmo]

At any parts store they should have the tool to do that. It is a clam looking thing with a section closest to the line that goes into the groove there and releases a spring retainer. Clam in around the line gently/firmly push it towards towards the fuel pressure regulator, it will only go 1/4 inch or so, then while holding it in place pull firmly on the line, the tool will come with the line.



[hubdawg]

Yes I saw them at autozone the other day. THey have a set of four.. they are four round colored tools. Just tell the counter guy you want to undo fuel lines on your ford.. there are 4 or 5 specialized tools for all the diff connectors they use.



[wayprow09]

Can anyone help me? I need it for class and I know how to fix it but I just do it to slow. It takes me a longer time for my way, Please help me.



[andre]

like he say any good parts store go it cost around 14.oo$ s for set

this connector as inside a round spring that hold it to pipe tool expand the spring to take it off

just have to push tool in lip thend ill come out

good thing to spray penetradting oil on connector before you try to remove it



[BroncoJoe19]

Here is a picture of the tool that makes this job possible



[Skyhigh351]

I had to disconnect the same line, I tried and tried for so long, then went out to the parts store and the guy told me I needed a special tool to take the fuel lines apart, it didn't cost much, I thnk I paid like 25 buck or somethin like that,

and it a hole set of diff sizes, you won't be able to pull it off with out a tool trust me,
